Single Channel Drain – 8′ (not extendable)


12 in stock

SKU: 16CD-8 Categories: ,


The 8′ bolt on channel drain is made from robust 12 gauge galvanized steel. All our pre-engineered channel drains are pre slopped. They are all built with an internal slope (.83%) allowing level installation and still maintain water flow. Our Channel drains have a sleek ¾” slot which creates a high end look which provides a low maintenance option VS a heavy non visible appealing traditional grating system. Walk or drive over with no concern. Easy install, everything comes assembled, no welding required, no heavy grating to bolt on. Simply bolt the sections together and pour your concrete. The channel drains can be installed on one or both sides of the drain pit. (It can not be bolted together to get a 16′ length on one side)
Tools required: 9/16” socket or wrench, string line or line laser, tape measure, hammer

Additional information

Weight 50.3 lbs
Dimensions 96 × 8.55 × 8.55 in
